mpression

IEEE1588™ Protocol Stack Package

Time synchronization complying with IEEE1588 standard

Category: Company: Mpression



IEEE1588 Protocol Stack Package complies with IEEE1588 standard and achieves high precision time synchronization with accuracy of 100 nanoseconds or lower. In addition to IEEE1588-2008 compliance, this package is also compliant with SMPTE2059 which is a profile for broadcast equipment. IEEE1588 is a standard for time synchronization scheme between network-connected devices.

PTP Version PTP version2
Clock Type Ordinary Clock(Slave)
Ordinary Clock(Master)
Supported Profiles Delay Request-Response Default PTP profile
Peer-to-Peer Default PTP profile
SMPTE2059 profile
Synchronization Message Two Step
One Step
Delay Mechanism End to End
Peer to Peer
Compensation Mechanism Phase Compensation
Frequency Compensation (both hardware compensation and software compensation)

IEEE1588 Protocol Stack Package PDF
